DTS-7002T is a module perfectly suited for receiving the ever-growing Digital Terrestrial Broadcasting.

This module can be easily adapted to Various Displays. (Digital TV, Second TV, Digital STB, etc.) Besides, DTS-7002T is able to reduce the development term.

You can experience both outstanding stability and high performance in this affordable module loaded with very best technology.

Basic Features
MPEG-II Digital & Fully DMB-TH compliant.
256Color OSD(on screen display) support(Chinese, English)
PIG(picture in graphic) support
EPG(Electronic Program Guide) & Information-Plate support
Multi-lingual Audio support
Channel search in automatic, manual and network
Max. 500 channels receivable
5 favorite channel groups support (Max. 40 channels in each group).
Channel list mode in All, Favorite, Scrambled
Channel sorting by channel number, Alphabet, FTA
Software Upgrade service.
Parental control with block on system, all channels and programs by age limitation.
Timer setting(Automatic Turn on & off daily) and GMT, Time Offset support
Extended information shows the full program information
Auto language selection of program for Audio language with user setting in menu.
Optional Features
DVB-C Module
MODEL : FTA / CI / CAS
Specification
Tuner & Channel
Frequency Range 48.5MHz to 226.5MHz (VHF)
470MHz to 862Mhz (UHF)
Signal Level -10 to -70dBm
Mode 2k, 8K
Demodulation OFDM
Guard Intervals 1/4, 1/8, 1/16 & 1/32
FEC mode 1/2, 2/3, 3/4, 5/6 and 7/8
Video Decoder
CPU Chips&Media CMS2131ADM
Transport Stream MPEG-2 ISO/IEC 13818 Transport Stream Specification
Profile Level MPEG2 MP@ML
Video Input Rate 15Mbit/s Max
Aspect Ratio 4:3, 16:9
Video Output CVBS, RGB(Optional), ITU656
Audio Decoder
Audio Decoding MPEG/MusiCam Layer I/II
Audio Mode Single /Dual Mono/Joint Stereo/Stereo
A/V & Data In / Out
Video RCA Video Output (CVBS), RGB(Optional), ITU656
Audio R/L Audio R/L Output (Volume and Mute control),
I2S(Resolution: 20 bits DAC, MAX. 2Vrms)
Interface
Command Interface UART
Physical Specifications
Dimension About 60mm×120mm

※ The specifications are subject to change without notice.
