 Personal Video Recorder |
 Time Shift Recording function
Background recording function
(while live channel viewing & TSR)
Picture In Picture (2 tuners)
Position move function
Pause and Play with button during A/V watching
Jump to live program
Slow Motion function
Automatic rewind for a time
and play with button (Instant Replay)
Recording live channels and stop
Recording reservation in EPG information
Recording reservation
with setting start time and duration
Play back of recorded services
with Trick play modes
Front cartridge type HDD storage
Recording Capacity-120H /250GB for 4Mbps Stream |
| Digital Set-top box |
Scrambled channel receivable with DVB CI
MPEG-II Digital & Fully DVB-S compliant.
256 Color OSD support
(Multi-languages support, default English)
User-friendly EPG and Information Plate
Installation Wizard helps easy
and automation installation step by step
S/W Upgrade via USB, OTA or serial connection (RS-232C)
Channel search in automatic, manual and network search
Channel list mode in ALL, Favorite, Satellite, Scrambled
Channel sorting by TV/Radio, Channel Number, Alphabet, Satellite Group and FTA
Finding channels by name (Optional)
Max. 5000channels receivable
5 Favorite channel groups(Max. 100 channels in each)
DiSEqC 1.0, 1.2, 2.0 and USALS support
Timer setting(Automatic Turn on & off daily)
and GMT, Time Offset support
Subtitle supports EBU and DVB subtitle
OSD Teletext Decoding & VBI teletext support
Dolby Digital Audio Output (Optical)
Auto language selection of program for Audio language
Video format in 4:3, 16:9 and letterbox
Parental control with block on system, all channels and programs by age limitation
Extended information shows the full program information |
| Optional |
Model : FTA/ CI / CAS
Support Nordig Specification
Support USB 2.0
Support HDMI output
Digital album with slide show(JPEG, Bmp, etc.)
- Thumbnail and Digital photo frame on TV
MP3 file play |
| Other Product |
| NPR-5300S
: NSB-5300S + External PVR |
| Specification |
| Tuner & Channel |
| Demodulation |
DVB-S & DVB-S2 |
|
| No. of Tuner |
1 |
|
| Signal Level |
-25 to -75dBm |
|
| RF Input Connector |
F-type, IEC-169-24, Female |
|
| DiSEqC Control |
1.0, 1.2, USALS compatible |
|
| Frequency Range |
950MHz to 2150MHz |
|
|
|
| MPEG Transport Stream A/V Decoding |
| Transport Stream |
MPEG-2 ISO/IEC 13818 Transport Stream Specification |
|
| Profile Level |
MPEG2 MP@ML/HL, MPEG-4 AVC/H.264 HP@L4 |
|
| Video Input Rate |
72.5Mbit/s Max |
|
| Aspect Ratio |
4:3 Pan & Scan, 16:9 Letter Box |
|
| Video Resolution |
1080i, 720p, 576p, 576i |
|
| Audio Decoding |
MPEG/MusiCam Layer I/II |
|
| Audio Mode |
Single Mono/Dual Mono/Joint Stereo/Stereo |
|
|
|
| A/V & Data In / Out |
| CI Slot |
1 |
|
| Smart Card Slot |
- |
|
| SCART |
TV & VCR(Option) |
|
| RCA |
1 Video & 2 Audio |
|
| Component |
YPbPr & HDMI |
|
| S/PDIF |
Optical Type |
|
| USB 2.0 |
DATA |
|
| DATA |
RS-232 & Ethernet(Option) |
|
| Internal HDD |
None |
|
|
| Power Supply |
| Input Voltage |
90 ~ 250V AC, 50/60Hz SMPS Type |
|
| Power consumption |
Max. 27W |
|
|
| Physical Specifications |
| Size | About 290 * 60 * 225mm |
|
| Operating Temp. |
0 to +45 Defree C |
|
| Storage Temp. | -10 to +70 Defree C |
|
|
| ※ The specifications are subject to change without notice. |
