¤ýNSB-3000T ¤ýNSB-5000T ¤ýNSB-5100T ¤ýNSB-5100DTMB

Our Products are perfectly wuited for receiving digital terrestrial broadcasts from free-to-view to encrypted services with conditional access system. From standard definition to high definition, they will give most clear, high quality, easy usable multimedia device to customer.

The NSB-3000T is a set-top box perfectly suited for receiving digital terrestrial broadcasts. Viewers can now enjoy both outstanding stability and comfort in this affordable set-top box loaded with the very best technology.

The simple installation and operation, user-friendly three dimensional OSD(On Screen Display), highest quality audio output and advanced video clarity are all designed to enrich the viewer experience.

In addition, NSB-3000T boasts the enhanced EPG(Electronic Program Guide) and information plate on programs and broadcast signals.

Basic Features
Perfect View for FTA signal
High Sensitivity
256 or True color OSD
7-Days EPG
Multilingual menu, audio & subtitle
Teltetext supported by VBI insertion & OSD
2,000 services list
Favorite service lists
Fully DVB-T compliant
Nordig compliant
Additional Features

USB 2.0 for SW upgrade
Component(Y/Pb/Pr) & HDMI
PVR, Photo Viewer, Music Player via USB
Variety of A/V output
CI or CAS support
High Definition signal receiving
MPEG-2/4/h.264 CODEC Supported
OTA

Other Models
NSB-3100T : NSB-3000T + 1 CI
NSB-3200T : NSB-3000T + Conax7
Specification
Tuner & Channel
Demodulation DVB-T
Waveform COFDM
Constellation QPSK, 16QAM, 64QAM
Freq. Range 45~230 MHz(VHF), 470~862MHz(UHF)
Input IEC 169-2 Female
Signal Level -10 to -76 dBm
MPEG Transport Stream & Audio/Video Decoding
Transport Stream MPEG-2 ISO/IEC 13818 TS Specification
Profile Level MPEG-2 MP@ML, H.264 LP@L3
Aspect Ratio 4:3 Pan & Scan, 16:9 Letter Box
Video Resolution 576i
Audio Decoding MPEG/MusiCam Layer I & II
Audio Mode Single/Dual Mono/Joint Stereo/Stereo
Audio / Video / Data In /Out
CAS -
SCART TV
RCA 1 Video & 2 Audio
S/PDIF Optical Type
DATA RS-232
Power Supply
Input Voltage 90 ~ 250V AC, 50/60Hz SMPS type
Power consumption Max. 10W
Physical Specifications
Size About 290 ¡¿ 60 ¡¿ 225(mm)
Operating Temp 0¡É to +45¡É
Storage Humidity -10 to +70 Degree C
